56m3 25mt 60m3 30mt LPG gas semi-trailer tank trailer

>> Part I : Introduction of Factory :Factory introduction:1. ChengLi Special Automobile Co.,Ltd, which was appointed by the Development and Reform Committee of China, is the biggest special purpose vehicle manufacturer in China.also we are famous manufacturer producing all kinds of special trucks for municipal &a

Featured Products

>> Part I : Introduction of Factory :

Factory introduction:
1. ChengLi Special Automobile Co.,Ltd, which was appointed by the Development and Reform Committee of China, is the biggest special purpose vehicle manufacturer in China.also we are famous manufacturer producing all kinds of special trucks for municipal & environmental construction, virescence, petrol & medicals, container, and semi-trailer. Brands registered include CLW.Our company has independent export right and has a mount of clients in overseas. Our leading varieties include more than 100 types of trucks and related products such as water truck, fecal suction truck, garbage truck, refuse compactor, sewage suction truck, fuel tank, high-altitude operation truck, truck with crane, dump truck, instructional truck, van truck, semi-trailer, fire engine, refrigerator truck, water wagon, tractor, high-altitude water truck, bulk cement truck, chemical liquid truck, concrete mixer truck, and others.

2.Our company has solid technology, flawless inspection, advanced equipment, reliable quality and flexible modes of operation. What's more, our company has roundly passed ISO9001:2000 and CCC (China Compulsory Certification) certifications. Series trucks of Cheng Li have procured remarkable achievements interiorly, especially from the investment in South Suburb Cheng Li Automobile Industry Park.
 We have been in this field for over 10 years, we have more than 300 types  of special trucks, our workers are more than 1000 and factory is more than 690,000m2 .We have successfully exported our trucks to Ghana, Sudan, Nigeria, Tajikistan, Namibia, Burma, Korea, Iran, Iraq, Vietnam etc. many Africa & Asia countries more than 4000 trucks every year.

3.Quality control:our company truck pass ISO,3C,BV certification.
our factory have the quality Quality Inspection Department.before sending truck for facotry ,our quality inspection department will check the truck carefully.

4.Design capacity :Our factory have 30 technician and designer.

5. Exhibition:our factory attend the Guangzhou Trade Fair each year.

6. Export market: Africa,Asia,South America,Pacific and so on

7.Our company cooperate with famous chasis manufacturers,such as DONGFENG,FAW,SHINOTRUK,IVECO,FOTON,SHACMAN,Yuejin , ISuzu China , Jac and all chassis supplier in China .


>>Part II :56m3 25MT 60m3 30MT lpg gas  semitrailer tank trailer
vehicleVehicle TypeLPG Semi-trailerTankdesigned pressure1.77Mpa
Vehicle NameLiquefied gas semi-trailerMax worked pressure1.60Mpa
Overall dimension12900×2500×3980designed temperature50ºC
Actual Capacity56M3filling mediumpropylene
Curb weight 16480corrosion allowance 1.0mm
Real capcity23520Kgcapacity56M3
AxleFrong axle:15390Kg
Rear axle:23040Kg
heat treatmentWhole body
rear overhang1450tank dimension12515×2478mm
departure angle-/26Tank thickness12.5mm
axles load24000(three axles)tank materialQ345R
wheel base6800+1310+1310Water pressure test pressure2.66MPa
Number of tires12aritightness test pressure1.77MPa
tire specification12R22.5safety valueModelA412F-2.5-16
rear track base1840/1840/1840Nominar pressure2.5Mpa
Level gaugeModelYWJ-25Nominar diameterDN80
Typerotary tube gageValve Dia53mm
Nominar pressure2.5Mpaunseal pressure2.27-2.37Mpa
test range50-2450mmreseating pressure0.9times than unseal pressure
precision2.5Opening pressure1.90MPa
loading and unloading deviceModelgas phaseYKAG-3.3-6
cut deviceModelgas phaseQGJ43F-2.5-8liquid phaseYKAG-3.3-7
liquid phaseQGJ43F-2.5-7Nominar diametergas phaseDN25
Nominar diametergas phaseDN25 liquid phaseDN50
liquid phaseDN50nominar pressure3.3Mpa
operated methodpullout Mechanical typeTypequick fitting
semienclosed cutout temperature70±5ºCSpecial functionActual capacity is 56M3,BPW axle 13T,safety valve ,JOST outrigger ,Liquid Indicator ,pressure indicator,termperature indicator,Emergeny Cut-off Valves ,fire bottle ,antistatic earthing tape ,protective guard ,tire security board ,
Typecombine cut value and overload limited value
cut time10s

Photo of 56m3 25MT 60m3 30MT lpg gas  semitrailer tank trailer

56m3 25mt 60m3 30mt LPG Gas Semitrailer Tank Trailer
56m3 25mt 60m3 30mt LPG Gas Semitrailer Tank Trailer
56m3 25mt 60m3 30mt LPG Gas Semitrailer Tank Trailer


56m3 25mt 60m3 30mt LPG Gas Semitrailer Tank Trailer
>>Part III : Certification of Factory
56m3 25mt 60m3 30mt LPG Gas Semitrailer Tank Trailer

>>Part IV :Shipment Option

56m3 25mt 60m3 30mt LPG Gas Semitrailer Tank Trailer

>>Part V:FAQ

Q1. Your service
A:Our services
1. we can send our technician to arrive the customer's country to provide the service and also we can train customer's workers for free.
2. free consultation forever. When you meet small problems, professional advices can help you to solve them soon.
3. One year free cost warranty.
4. Spare parts forever. When you need spare parts, we can send them to you immediately.

Q2. What is your terms of payment?
A: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages before you pay the balance.

  LC terms is also can be accepted .

Q3. What is your terms of delivery?
A: EXW, FOB, CFR, CIF, DDU.DAP etc .

Q4. How about your delivery time?
A: Generally, it will take 10 to 20 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.

For standard products, delivery time is as below:

Water tanker truck:7 days
Fuel tanker trailer:15-20days
Garbage truck:15 days
Sweeper road truck:25 days
Wecker truck:7-10 days
Suction sewage/Fecal truck:7-15 days
Crane truck:15 days
Refrigerator/Van truck:7-15 days
Dump truck:20 days
Concrete mixer truck:7-25 days
LPG :20-30 days
LED truck:7-15 days
(the above is left hand drive chassis ,if you need the right hand drive chassis ,delivery time is longer than Left hand drive truck,Detailed clauses are subject to contract .)

Q5. Can you produce according to the samples?
A: Yes, we can produce by your samples or technical drawings. We can build the molds and fixtures.

Q6. How to control truck quality?
A: we have Rich experience workers and engineer to control quality before and on production , we strictly followed STATE special truck technical specification and safety production specification .

We have been in this line for over 15 years, dealing with all kinds of special trucks and trailers.


Q7. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery


Q8: How do you make our business long-term and good relationship?
A:1. We keep good quality and competitive price to ensure our customers benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends with them,no matter where they come from.



Q9. Did you sell truck to our country before?

A:Our main market is Africa, Asia, South America , Oceania ,middle east , annual sales is around 5000units and keeping growing every year .



Q10,If you have no certificate for exporting trucks to our country , what should we do?

A:There are some regions and countries we can not export completed truck but we can make body according to your requirements and send to you , you install it on your own chassis and sell completed truck .this can help you to save cost and  increase competitiveness
