100cbm High Pressure LPG Stprage Tanker LPG Gas Tank For Sale

100CBM high pressure LPG stprage tanker LPG gas tank for saleLPG Tank, LPG gas storage tank, LPG gas cylinder tank. LPG tank Truck, LPG mobile tank Trailer.CHENGLI SPECIAL AUTOMOBILE Co., Ltd, which is famous LPG manufacturer in ChinaLPG tank for storage from 5000 liter to 200000 literLPG tank truck with gas refil

Featured Products

100CBM high pressure LPG stprage tanker LPG gas tank for sale

LPG Tank, LPG gas storage tank, LPG gas cylinder tank. LPG tank Truck, LPG mobile tank Trailer.

CHENGLI SPECIAL AUTOMOBILE Co., Ltd, which is famous LPG manufacturer in China

LPG tank for storage from 5000 liter to 200000 liter

LPG tank truck with gas refilling device from 5000 liter to 35000 liter

LPG mobile tank trailer from 30000 liter to 60000 liter, which also could install refilling device.

LPG filling plants from 5000 liter to 120000 liter,which have different model for choice and accept customized design

Detail specification





The Main Parameter
Vessel volume100000Literscontainer inner diameter3200mmThe container (high)13016×3826mm


material

shell
Q345R

Thickness

shell
18mm
Shell weight
 20400  kg

head
Q345R
head
18mm
Internal parts weight
/        kg

lining
/
lining
/  mm
Filling weight
39900 kg

jacketed
/
jacketed
/  mm

Design Pressure

Shell side
1.77MPa

temperature designed

Shell side
50 ºC
maximum allowable working pressure

Shell side
/

Tube side
/   MPa
Tube side
/   ºC
Tube side
/

jacketed
/   MPa
jacketed
/   ºC
jacketed
/

 shell side medium

Liquefied petroleum gas

Tube side medium
/
Jacketed medium
/


Structural type

The main structure type

Elliptical head round tanks

installation type

Fixed horizontal installation

Supporting type

Saddle support

Insulation way
-

Test and Inspection

Method of Non-destructive Testing
RT  MT  PT
Proportion Of Nondestructive Testing
100%

Pressure Test Type

Hydraulic pressure test

 test pressure
2.22MPa

Heat-treatment Method

Stress Relieving Heat Treatment

Heat-treatment Temperature
620±15ºC
    Safety accessories and related equipment
  Name   Type   Size   Quantity   Self-provided

Magnetic reprint level gauge
UQZ-6   DN26001/
Safety ValveA42F-25DN501GB12243,Pz=1.69MPa,  K=0.65
   Pressure gaugeY-150M20×1.511.6.0-4Mpa
  ThermometerWTQ-280    M33×21-40ºC-60ºC,1.5


 Manufacture and Supervisory  Situation
 Supervisory Agency
Hubei Special Equipment Inspection Testing Institute
  Organization Code42000423-5
Organization Verification Certificate No.
TS7110215-2019
100000l LPG tank detsil for reference

100cbm High Pressure LPG Stprage Tanker LPG Gas Tank for Sale
100cbm High Pressure LPG Stprage Tanker LPG Gas Tank for Sale
100cbm High Pressure LPG Stprage Tanker LPG Gas Tank for Sale


100cbm High Pressure LPG Stprage Tanker LPG Gas Tank for Sale100cbm High Pressure LPG Stprage Tanker LPG Gas Tank for Sale

If you want to chat more detail and price, please feel free to contact:

THANKS FOR REFERENCE
