LPG Tanker Truck, 25 Ton 57000 Litre LPG Tanker Semi Trailer For Sale

3 axles LPG tank semi trailerContact:AliceTEL: +86-531-69985132FAX: +86-531-69985133Tel& : 0086 182 5311 2969 1Dimensions(length*width*height)13000*2500*3995(mm)1ProductsLPG, Butane , Propane 2Fluid propertyflammable4Design temperature

Featured Products

3 axles LPG tank semi trailer

Contact:Alice
TEL: +86-531-69985132
FAX: +86-531-69985133
Tel& : 0086 182 5311 2969


1

Dimensions(length*width*height)

13000*2500*3995(mm)

1

Products

LPG, Butane , Propane

2

Fluid property

flammable

4

Design temperature

50°C

5

Design pressure

1.61MPa

6

Corrosion allowance

1.0mm

7

Major materials of bearing pressure

Tanker body : Q345R , 12.5mm

End plate : Q345R , front:10mm,Rear:12.5mm

Main Beam : T700

8

Filling weight per volume

420Kg/m3

9

Compartments

One

10

Baffle inside the tank

14-off Aluminum bolted plate , thickness is 6mm

11

Shape

Cylindrical ; Ellipse head

Detection

1

Heat treatment

Overall heat treatment in a furnace , 500°C to 560°C

2

Flaw detection

100% Flaw detection

3

Hydrostatic test

2.1MPa

4

Magnaflux

Aim at welding place flaw detection can not cover

Manhole (As customer's requirement )

1

Quantity

1 ; On top

Safety Valve (As customer's requirement )

1

Quantity

Two

2

Location

On the top of tanker ;

3

Type

Only weld suitable flange

4

Size

As customer's requirement

Liquid meter (As customer's requirement )

1

Quantity and Model

1

2

Location

On left side of tanker

3

Type

Only weld suitable flange

4

Size

As customer's requirement

Valve and pipe Detail (As customer's requirement )

Running System

1

Axles

3

13 TON FUWA Axles

2

Suspension system

1

FUWA Air suspension

4

Tyre

12

Brand : Triangle,12 R22.5 vacuum

5

Kingpin

1

90#/50#

6

Landing legs

1

28Ton FUWA

Pneumatic Brake System

1

Spring brake chamber

6

FUWA

2

Air connector

1

FUWA

3

Relay Valve

1

BRAND:WABCO

4

ABS

1

WABCO ABS

Electronical System

1

7-Pin Socket

1

24V 7-pin socket

2

LED Lamp

1

All kinds of lamp

3

Cable

1

Stander cable

LPG Tanker, 25ton 57000L LPG Tanker Semi Trailer for Sale
LPG Tanker, 25ton 57000L LPG Tanker Semi Trailer for Sale
LPG Tanker, 25ton 57000L LPG Tanker Semi Trailer for Sale
LPG Tanker, 25ton 57000L LPG Tanker Semi Trailer for Sale
LPG Tanker, 25ton 57000L LPG Tanker Semi Trailer for Sale
LPG Tanker, 25ton 57000L LPG Tanker Semi Trailer for Sale
