dongfeng 4x2 fuel tank truck 4000-5000liters
Product information
| Main Specification | |
| Product Name | HOWO fuel tank truck 5000liters |
| Truck model | CLW5060GJYZ3 |
| Driving Type | 4×2,right hand drive |
| Weights | |
| Max.Payload (kg) | 5000 |
| Curb weight(kg) | 3500 |
| Dimensions | |
| Wheelbase (mm) | 3360 |
| Overall Dimension (mm) | Approx.5995×1980×2300 |
| Box dimension | 5000liters |
| Engine | |
| Engine Model | CY4102BZLQ (120HP) OR Yunei 116hp |
| Engine type | 4 stroke water-cooled, Inter-cooling,Turbocharged |
| Displacement (L) | 3.856L |
| Rated power Rev ((Kw/rpm) | 88kw/2800rpm |
| Max Torque (N*m)/Rev (rpm) | 392N.m/1400-1800rpm |
| Emission standard | EURO 2 |
| Drive Line | |
| Transmission | WLY6T100,6 forwards, 1 reverse gear, manual operation |
| Steering | With power steering |
| Brake system | Air brake |
| Cab | |
| Cab | Single row, Howo cabin, A/C optional |
| Axles | |
| Front axle | 2 tons |
| Rear axle | 3.5 tons |
| Tire specification | |
| Tire specification | 7.00R16 standard tire,6 tires+1 spare tire |
| Specification of Fuel truck | |
| Tank capacity | 5000liters,one compartment |
| Tanker material | Q235, carbon steel |
| Manhole | 1 pcs manhole fixed on top of tank |
| Outlet and inlet | 1 pcs outlet and 1 pcs inlet |
| Oil rope | 2 pcs oil rope |
| Fire extinguisher | 2 pcs 4kg fire extinguisher |
| Anti-static devices | Including ground towing, static line plate |
| Pump | Equipped Oil pump (driven from gearbox by PTO) |
| Model:60YHCB-30 | |
| Flow:30m3/h | |
| Pressure :0.4Mpa | |
| Rotate Speed:970r/min | |
| Fuel dispenser | this dispenser can use for diesel and gasoline |
Company information
1. ChengLi Special Automobile Co.,Ltd, which was appointed by the Development and Reform Committee of China, is a famous manufacturer producing all kinds of special trucks for municipal & environmental construction, virescence, petrol & medicals, container, and semi-trailer. Brands registered include CLW .Our company has independent export right and has a mount of clients in overseas. Our leading varieties include more than 100 types of trucks and related products such as water truck, garbage truck,sewage suction truck, fuel tank, high-altitude operation truck, truck mounted crane, dump truck, LED advertising truck,LPG truck/trailer,LPG filling tank, van truck, semi-trailer, fire engine, refrigerator truck, tractor, bulk cement truck, chemical liquid truck, concrete mixer truck, and others.
2.Our company has solid technology, flawless inspection, advanced equipment, reliable quality and flexible modes of operation. What's more, our company has roundly passed ISO9001:2000 and CCC (China Compulsory Certification) certifications. Series trucks of Cheng Li have procured remarkable achievements interiorly, especially from the investment in South Suburb Cheng Li Automobile Industry Park.
3.Quality control:our company truck pass ISO,3C,ASME certification.
our factory have the quality Quality Inspection Department.before sending truck for facotry ,our quality inspection department will check the truck carefully.
our factory have the quality Quality Inspection Department.before sending truck for facotry ,our quality inspection department will check the truck carefully.
4. Export market: Africa,Asia,South America,Pacific and so on
5.Our company cooperate with famous chasis manufacturers,such as DONGFENG,SHINOTRUK,FOTON, JAC,JMC ,SHACMAN,FAW and etc.
Service
1.We can product truck accroding the customer's requirments(color,size,logo and so on)
2.We can send our technician to arrive the customer's country to provide the service .
3.We can train customer's workers for free.
4.Our truck warranty:12 months.we can provide the parts for free at the frist year.
2.We can send our technician to arrive the customer's country to provide the service .
3.We can train customer's workers for free.
4.Our truck warranty:12 months.we can provide the parts for free at the frist year.
Success Case Show
FAQ
1.Payment term.
-T/T,30% deposit ,and pay the blance before shippment from our factory
-L/C,L/C price is expensive than T/T price.
-T/T,30% deposit ,and pay the blance before shippment from our factory
-L/C,L/C price is expensive than T/T price.
2.What about quality ?
Our truck are brand new truck,Our survival is based on quality and credit standing is the guarantee of our success. We will do as we can to treat customers honestly, manage flexibly, guarantee high quality but low price, and keep high efficiency.
our company truck pass ISO,3C,ASME certification.
Our truck are brand new truck,Our survival is based on quality and credit standing is the guarantee of our success. We will do as we can to treat customers honestly, manage flexibly, guarantee high quality but low price, and keep high efficiency.
our company truck pass ISO,3C,ASME certification.
3.Visit our factory
Our factory are in suizhou city,hubei province china.
You can take train or plane to arrive wuhan citry(wuhan city is the capital of hubei province) .and our driver will pick up you at wuhan railway station or wuhan tianhe airport.
Our factory are in suizhou city,hubei province china.
You can take train or plane to arrive wuhan citry(wuhan city is the capital of hubei province) .and our driver will pick up you at wuhan railway station or wuhan tianhe airport.
And if need the invitation letter ,pls send your private information and company information to me.
